50-002SF Class 66/5 Sound fitted

Only 1 left
SKU: 50-002SF
£339.95 inc. VAT

Bachmann  50-002SF

Sound Fitted
Class 66/5 locomotive
Freightliner

number 66606
Dcc Sound Fitted

DETAIL VARIATIONS SPECIFIC TO THIS MODEL

  • Original 4-Door Locomotive
  • 3-Piece Cab Side Windows with Separate Quarterlights
  • Original WIPAC Light Clusters (3-Lamps)
  • Small Top Light Box
  • Standard UK Pattern Buffers
  • Combination Drawgear with Buckeye Couplings
  • Standard Horn Box
  • NRN Radio Pod on Roof
  • 4 Cab Vents
  • 2 Securing Lugs at each End
  • Cab Front Handrails with 5 Mounting Points
  • Cab Interiors with Pedestal Control Panels
  • Original Sandboxes
  • Angled Sandpipe Brackets
  • Smooth Bogie Lifeguards
  • Cab Front Steps



BACHMANN BRANCHLINE CLASS 66 SPECIFICATION

MECHANISM:

  • Five pole, twin shaft motor with two flywheels providing drive to both bogies
  • All axle drive
  • Electrical pickup from all wheels
  • Separate metal bearings fitted to each axle
  • Diecast metal chassis block and bogie towers
  • Diecast metal gearboxes, with gearing arranged for prototypical running speeds and haulage capabilities
  • 5mm (OO gauge) wheels to NEM310 & NEM311 standards with authentic profile and detailing
  • Close coupling mechanism fitted at each end, each of which is fitted with coupling pockets to NEM362 standards
  • Auto-Release Couplings fitted at both ends – DCC operated, hands-free uncoupling with the press of a function button (SOUND FITTED DELUXE models only)
  • Designed to operate on curves of second radius (438mm) or greater

DETAILING:

  • Precision moulded bodyshell and locomotive main frames, with numerous separately fitted parts including horn boxes, fuel tanks, battery boxes and sand boxes
  • Separately applied metal detail parts, including cab-front steps, securing lugs, lifting points, lamp brackets, and cab door handrails
  • Individual pipe and cable runs added to the main frames, underframe and bogies
  • Bogies constructed from multiple components featuring full relief detail
  • Separately fitted axle heads on each wheel which rotate smoothly and authentically when the model is moving
  • Close-fitting bogie to main frame interface providing an authentic appearance and accurate ride height
  • Etched roof, bodyside and horn grilles, with multi-part bodyside cooler group grilles and multi-layered internal partitions providing visibility through the full width of the locomotive
  • Sprung metal buffers
  • Cab interior detailing which includes the control desk, cab seats, hotplate and rear partitioning and doors, complete with extensive interior decoration
  • Alternative front valances with/without coupling cut-outs – interchangeable by removing two screws and without the need for body removal
  • Each model supplied with a full set of decorated, model-specific bufferbeam pipework and accessory parts

LIGHTING:

  • Directional lighting, switchable on/off at either end on DCC or Analogue control
  • Day/Night mode, selectable on DCC or Analogue control
  • Directional lights and Day/Night Mode selection is controlled via easy-access switches on the roof when operated on Analogue control
  • Stabling lights mode* (red tail lights only, displayed at both ends)
  • Cab lighting*, assigned to two DCC functions for separate switching of each
  • Separately switched Machine Room lighting* (*when used on DCC)
  • Authentic light colours and temperatures selected for each model based on era and application

DCC:

  • Plux22 DCC decoder interface
  • Easy-access DCC decoder socket via a removable roof panel – magnetically secured
  • Bach-Up Stay Alive System providing uninterrupted power to prevent stalling, light flicker and sound cut-outs (operates on DCC only)

SOUND:

  • Speaker Fitted – a pre-fitted speaker is included with every model as standard
  • Dual Fitted XL Speaker System – SOUND FITTED and SOUND FITTED DELUXE models feature two speakers, including our new speaker with enhanced bass reproduction – a patented component which incorporates a passive radiator design for optimum sound performance
  • ESU Loksound V5DCC Sound Decoder fitted to SOUND FITTED and SOUND FITTED DELUXE versions
  • Sound files produced specifically for the Bachmann Branchline Class 66 using recordings from real locomotives
  • SOUND FITTED and SOUND FITTED DELUXE models operate on DCC and Analogue control as supplied. On Analogue, an authentic engine start up sequence and running sounds are produced when power is applied

LIVERY APPLICATION:

  • Authentic liveries applied to all models
  • Multiple paint applications employed on each model using original specification colours
  • Logos, numerals and text added as appropriate using multi-stage tampo printing using authentic typefaces, logos and colours
